1. STIG Manager OSS Setup and Technical Information

The STIG Manager open-source project provides an API and Web Client designed for deployment in various environments - from single laptop demonstrations to enterprise-level orchestrations. While containerization is recommended for security, scalability, and maintenance benefits, the application supports multiple deployment methods to meet diverse organizational requirements.

Note

All deployments require integration with deployer-provided infrastructure services. This document provides configuration guidance while respecting that deployers will have varying needs and requirements for their specific implementations.

1.1. Architecture & Core Components

Component Diagram

1.1.1. Required Components

Every STIG Manager deployment consists of:

STIG Manager API (Core Component, provided by the STIGMan project)

  • RESTful API on Node.js LTS with Express framework

  • Stateless service exposing a single HTTP port

  • Handles all application logic and data operations

  • No persistent storage - all data flows to MySQL

Web Client (User Interface, provided by the STIGMan project)

  • Single Page Application using ExtJS 3.4

  • Served as static content from the API container

  • Provides interactive access for users

OpenID Connect (OIDC) Provider (Authentication Service, deployer-provided)

  • Manages user accounts and authentication

  • Issues OAuth2 JWT tokens for API access

  • Tested providers: Red Hat Keycloak, Okta, F5, Azure Entra

  • Must support Authorization Code Flow with PKCE for web clients

MySQL Database (Data Persistence, deployer-provided)

  • Stores all application data

  • Supports TLS and mutual TLS authentication

  • Version 8.4+ recommended for optimal performance

  • Deployer responsible for backups and security

Important

STIG Manager provides only the API and Web Client. All other components (OIDC Provider, MySQL, reverse proxy) must be provisioned and configured according to your organizational requirements and security policies.

1.2. Critical Configuration Requirements

Before deploying STIG Manager, ensure your infrastructure meets these essential requirements:

1.2.1. Database Configuration

MySQL 8.0+ is required with proper configuration for performance and security.

Key Requirements:

  • Dedicated database/schema with appropriate grants

  • Buffer pool sized for your deployment (8GB minimum)

  • TLS support for secure connections

  • Regular backup strategy

MySQL setup and configuration

1.2.2. Authentication (OIDC) Configuration

STIG Manager requires an OpenID Connect provider for authentication and authorization.

Key Requirements:

  • Support for Authorization Code Flow with PKCE

  • Proper JWT claims configuration (username, privileges, scopes)

  • CORS configuration if OIDC and API are on different domains

  • User privilege mapping (admin, create_collection, user roles)

Authentication setup and JWT requirements

1.2.3. TLS and Proxy Configuration

Important

The STIG Manager Web Client requires a secure context (HTTPS) to function. For non-localhost connections, you must configure either native TLS or deploy behind a reverse proxy providing HTTPS. Localhost connections (127.0.0.1, ::1) can use HTTP.

STIG Manager supports native TLS connections configured via environment variables. A reverse proxy is only required for mTLS/CAC authentication or when mandated by environmental requirements.

Native TLS:

  • Configure HTTPS directly using environment variables

  • No reverse proxy needed for basic TLS encryption

  • See Environment Variables beginning with STIGMAN_API_TLS_* for TLS configuration options

Reverse Proxy (when required):

  • Required for mTLS/CAC/PKI client certificate authentication

  • Must support streaming responses and Server-Sent Events (SSE)

  • Must handle unbuffered responses for specific endpoints

  • See Proxy configuration for details

1.3. Additional Suggested Configuration

1.3.2. Add Extra CA Certificates

If your deployment requires trusting additional Certificate Authorities (CAs) beyond those built into Node.js, you can provide these via a file. You might do this if the API is connecting to an OIDC Provider using https. You can set these specifically for STIG Manager by using the STIGMAN_OIDC_CA_CERTS environment variable to point to a file containing the additional CA certificates in PEM format. See Environment Variables for TLS configuration options.

Alternatively, set the NODE_EXTRA_CA_CERTS=file-path Node.js environment variable to direct Node itself to accept CA certificates you have provided, in addition to its built-in CA certs. If using containers and an external CA file, ensure this file is mounted into the container at that path.

Iron Bank images include DoD certificates at: /etc/pki/ca-trust/source/anchors/Certificates_PKCS7_v5.7_DoD.pem Check the Node.js documentation for more information.

1.3.3. Logging and Monitoring

STIG Manager outputs structured JSON logs to STDOUT for collection by your logging infrastructure.

Logging reference

1.3.4. Security Hardening

For deployments requiring compliance with security frameworks:

Key Areas:

  • Container security and image scanning

  • ASD STIG compliance considerations

  • Data flow and access control validation

  • TLS configuration for all components

Security and assessment guidance

1.3.5. Essential Environment Variables

STIG Manager is configured via Environment Variables

passed to the API container or process. At minimum, configure:

Database Connection:

  • STIGMAN_DB_HOST - MySQL server address

  • STIGMAN_DB_PORT - MySQL port (default: 3306)

  • STIGMAN_DB_USER - Database username

  • STIGMAN_DB_PASSWORD (unless using TLS for authentication)

  • STIGMAN_DB_TLS_CA_FILE - CA certificate file for TLS connection to DB

  • STIGMAN_DB_TLS_CERT_FILE (unless using password for authentication)

  • STIGMAN_DB_TLS_KEY_FILE (unless using password for authentication)

OIDC Integration:

  • STIGMAN_OIDC_PROVIDER - OIDC discovery URL for API

  • STIGMAN_CLIENT_OIDC_PROVIDER - OIDC URL for Web Client (if different)

API Configuration:

  • STIGMAN_API_ADDRESS - API bind address

  • STIGMAN_API_PORT - API port (default: 54000)

  • STIGMAN_CLASSIFICATION - System classification banner

Complete environment variables reference

1.3.6. Sample Orchestrations

The project provides reference implementations demonstrating these configurations:

1.4. Deployment Scenarios

Choose a deployment method based on your infrastructure and requirements:

1.4.1. Quick Start with Docker Compose

For demonstration or development environments, use our Docker Hub Quick Start orchestration.

Includes: STIG Manager API, Web Client, Keycloak, MySQL

Requirements: Docker and Docker Compose

1.4.2. CAC Authentication Deployment

For deployments requiring CAC/PKI authentication, see the STIGMan Orchestration repository.

Includes: Full stack with nginx proxy configured for CAC

Requirements: Docker Compose, PKI certificates

1.4.3. Individual Container Deployment

Deploy STIG Manager using Docker or any container runtime. Suitable for Kubernetes, OpenShift, or standalone Docker hosts.

Requirements:

  • Container runtime (Docker, Podman, etc.)

  • Configured OIDC Provider and MySQL database

  • Network connectivity between components

Basic Steps:

  1. Pull the image: docker pull nuwcdivnpt/stig-manager:latest-ironbank

  2. Configure environment variables for your infrastructure

  3. Run the container:

    docker run --name stig-manager -d \
-p 54000:54000 \
-e STIGMAN_DB_HOST=<DATABASE_IP> \
-e STIGMAN_OIDC_PROVIDER=<OIDC_URL> \
nuwcdivnpt/stig-manager

  4. Verify startup in logs: docker logs stig-manager

See Authentication Example - RedHat Keycloak 19 and Database - MySQL Latest 8.x for detailed component setup.

1.4.4. Deployment from Source Code

Run STIG Manager directly from source code using Node.js. Suitable for development or non-containerized environments.

Requirements:

  • Node.js LTS

  • Configured OIDC Provider and MySQL

  • Git (recommended)

Basic Steps:

  1. Clone repository: git clone https://github.com/NUWCDIVNPT/stig-manager.git

  2. Navigate to /api/source

  3. Install dependencies: npm ci

  4. Set environment variables

  5. Start application: node index.js

Tip

Use a process manager like PM2 for production deployments from source.

1.4.5. Deployment with Precompiled Binaries

Deploy using precompiled executables without requiring Node.js runtime.

Requirements:

  • Platform-specific binary from releases

  • Configured OIDC Provider and MySQL

Basic Steps:

  1. Download binary for your platform

  2. Set environment variables

  3. Run the executable

Tip

Use a process manager for production deployments.

1.4.6. Updating STIG Manager

Updates are straightforward due to the stateless API design:

  1. Deploy the new version with the same configuration

  2. The API will automatically handle any database migrations

  3. Check release notes for migration warnings on large datasets

Warning

Downgrading requires database restoration from a backup. Always backup before updates.

1.5. First Steps

1.5.1. Configure Users

Users are not created in the STIG Manager application itself. All users must be created and authenticated by your Authentication Provider (often, Keycloak), which must provide the appropriate tokens, scopes, and privileges before they can access the system. Upon first access after successful Authentication, STIGMan will create a user profile to which it assigns Collection Grants and assignments.

User privileges are controlled by the OIDC Provider. This can be done by configuring the OIDC provider to generate tokens for Users that include their privileges and scopes in the specified claims (STIGMAN_JWT_PRIVILEGES_CLAIM and STIGMAN_JWT_SCOPE_CLAIM). In most OIDC Providers, this can be done in multiple ways, depending on your use case. One option for Keycloak is using the “Role Mappings” tab for that user, or you can set these privileges as defaults using the Configure->Roles->Default Roles interface. See the Authentication and Identity section for more information.

Assign at least one User the admin privilege when setting up STIG Manager for the first time.

STIG Manager User Types, STIG Manager Privileges, and possible Keycloak Roles:

User Type

Privileges

Keycloak Roles

Administrator User

Access STIG Manager, Manage Collections, Import STIGs, Manage Users, Import/Export App data

admin, user

Collection Creator User

Access STIG Manager, Create Collections

user, create_collection

User

Access STIG Manager

user

Note

All Users must be explicitly granted access to Collections in order to see the Assets, STIGs, and Evaluations contained therein. Administrators can grant themselves or others access to any Collection.

It is recommended that most users should be “Collection Creator Users”(ie. assigned the “create_collection” privilege). Collection Creator Users can create and manage their own collections, as well as be assigned grants from other users.

STIG Manager will automatically create its own user associations for Collection grants once an authenticated user accesses the system. User Privileges (ie. “admin” and/or “create_collection”) are visible in the User administrative tab, but must be managed in the Authentication Provider. Specific Grants to Collections and Assets/STIGs are managed in the STIG Manager app.

1.5.2. Import STIGs

Up until this point, the setup has concerned the actual operational deployment of the app. For this function, and additional functions of the App, STIG Manager Users are required. See the User for more information on their different roles and privileges.

  1. Download the latest quarterly STIG Library Compilations from DISA and import it into STIG Manager.

  2. Log in to STIG Manager using an Administrator user to import STIGs. For information on how to do this, and other STIG Manager Admin functions, see the STIG Benchmarks portion of the STIGMan Application Manager (Administrator) Walkthrough.

For additional information about getting started with STIG Manager, see the Admin Walkthrough.
